MSR X6 Magnetic Stripe Card Reader Writer Encoder MSRX6How to instal the MSR X6 Software and then to Read and Write the cards.LINK FOR DOWNLOADhttps://www.se.
Cheap Control Card Readers, Buy Quality Security & Protection Directly from China Suppliers:MSR605X USB card magcard reader writer without Power adaptor compatible msr605 msr x6 MSR606i msrx6bt Enjoy Free Shipping Worldwide! Limited Time Sale Easy Return. Download MSR-BTX6 for PC free at BrowserCam. Designed MSR-BTX6 application just for Android operating system and also iOS but you might also install MSR-BTX6 on PC or MAC. You'll find few required guidelines listed below that you need to carry out just before you start to download MSR-BTX6 PC. How to Download MSR-BTX6 for PC or MAC. Free software for Windows and Mac OS. Misiri X6 Smallest USB 3 Tracks Mag VIP Card Reader Writer Encoder. But doesn’t support MAC OS. MSR 880 design with NFC.
The MSR606 card readers use the Prolific PL2303 Serial-to-USB Driver to interface the card reader on Windows.
1). Communication: Standard USB
2). 3-track version can read/write all three tracks data, 300-4000 oe
3). Program software for Windows 98/Me/XP/Vista/Windows 7/Windows 8 32bit or 64bit
4).Reading/Writing magnetic stripe card complied with ISO formats
1). Communication: Standard USB
2). 3-track version can read/write all three tracks data, 300-4000 oe
3). Program software for Windows 98/Me/XP/Vista/Windows 7/Windows 8 32bit or 64bit
4).Reading/Writing magnetic stripe card complied with ISO formats
Mechanical:
1). Body: ABS 94V-0 / Metal housing optional
2). Swipe: Manual, single direction
3). Outline: 212Lx64Wx63H mm
4). Weight: 1.4Kg approx.
Environment:
1). Operation: -10oC to 60oC 10 to 85% humidity, non condensing
2). Storage: -30oC to 70oC 10 to 90% humidity, non condensing
Consumption:
1). Current/operating Typical 350mA Max
2). 600mA plus for each writing track
3). Power supply: External switching Power, Input: 100-240VAC, Output: 9VDC 2A
Performance:
1). Read Circuit: Track 1&3: 210bpi Track 2: 75 or 210 bpi
2). Bit per Char: 5-7 bit per char.
3). Media Speed: Read, 5-50 ips (read speed 5-40 ips for track 2 at 210bpi)
Write, 5-30
4). Media Coercivity: Read 300-4000 Oe Mag. Card
Write 300-4000 Oe Mag. Card
5). Jitter Card: Read bit to bit interval <+/-15% card
Write bit to bit interval <+/-10%,Sub interval<+/-12% at 30ips
6). Low amplitude Card: Read 60% for both 75& 210bpi
7). Error Rate: Read < 0.5% Write < 0.8%
8). Media Swipe: Head life 1,000,000 passes for both read & write head
9). Configuration: Read/Write Track: 1&2&3
- Dynamag card reader supports USB HID or USB Keyboard emulation interfaces and is powered and connected via USB. Compatible operating systems: Windows and Android HID and KB mode. Mac OS in KB mode.
Just under 4 inches, Dynamag saves space on the countertop or in your custom build and still provides a long swipe path.
- The Red/Green/Amber LED status indicator keeps you in the know.
MagneSafe® is a digital identification and authentication architecture that safeguards consumers and their personal data. Designed to exceed PCI regulations, MagneSafe leverages strong encryption, secure tokenization, counterfeit detection, tamper recognition, data relevance and integrity, and dynamic digital transaction signatures, which together validate and protect the entire transaction and each of its components.
MagTek readers have one of the highest first swipe read rates in the industry. This enables you to develop reliable hardware and systems that move lines faster and makes your customers happy.
Secure transactions in-person, in-app, and on-line. Accept in-person payments curbside, at delivery, at the countertop, or table-side for card present and mobile wallet present transactions. Accept in-app or on-line payments via Magensa Hosted Payment pages thru links, QR Codes, or invoicing with touch free transactions that can be sent in-person or remotely for card not present transactions.
Standard Configurations
| Description | P/N |
| Black, USB swipe reader | 21073062 |
General Information
| Interfaces | USB HID USB Keyboard Emulation |
| Color | Black |
| Reference Standards | ISO 7810, ISO 7811, AAMVA |
| Recording Method | Two-frequency coherent phase (F2F) |
| Card Speed | 4 to 60 ips (10.1 to 152.4 cm/s) |
Electrical
| Power Input | 5V from USB bus |
| Current | |
| Normal mode | 110 mA maximum |
| Suspend Mode | 500 uA maximum |
Mechanical
| Dimensions | Length: 3.94†(100.0mm) Width: 1.28†(32.5mm) Height: 1.23†(31.3mm) |
| Weight | Weight: 4.5 oz. (127.57 g) |
| Cable Length | 6 ft. |
| Connector | USB Type A plug |
Environmental
| Temperature | |
| Operating | -30 °C to 70 °C (-22 °F to 158 °F) |
| Storage | -40 °C to 70 °C (-40 °F to 158 °F) |
| Humidity | |
| Operating | 10% to 90% noncondensing |
| Storage | Storage 10% to 90% noncondensing |
| Altitude | |
| Operating | 0-10,000 ft. (0-3048 m.) |
| Storage | 0-10,000 ft. (0-3048 m.) |
